The Model ST-350 Dynamic Strain Transducer is used for structural testing and recording strains on steel structures, post-tensioned and pre-stressed concrete structures, etc., and for any structure in which a short-term live-load can be applied. The Model ST-350 is delivered pre-wired in a rugged housing that is easy and quick to install in any weather. These transducers are field-proven and have been used for more than 20 years to record strain measurements on all types of structures, often in harsh field conditions.
Specifications
| Standard Range | ±4000 µε (approximately) |
| Effective Gage Length | 76.2 mm |
| Accuracy | ±2%, individually calibrated to NIST standards |
| Sensitivity | 500 µε/mV/V (approximately) |
| Circuit | Full Wheatstone Bridge with 4 active 350 ohm foil gages, 4-wire hookup |
| Temperature Range | −50°C to +120°C |
| Overall Size | 110.5×31.2×13 mm |
